Fishman AFX Pro EQ Mini Acoustic Preamp And EQ Pedal
PERFECT ACOUSTIC EQ CONTROL IN ONE COMPACT PEDAL
Based on the highly-regarded Fishman Platinum series of instrument preamps, AFX Pro EQ Mini offers quality preamplification and critical equalization voiced specifically for acoustic instruments.
AFX PRO EQ MINI ACOUSTIC PREAMP & EQ ACOUSTIC GUITAR PEDAL
5-Band EQ Specially Voiced for Acoustic Instruments
- True Bypass with Options for Buffered Bypass or Mute
- Feedback-Fighting Phase Control
- Innovative Dual Path Routing
- Super Compact Design Fits Almost Anywhere
9V External Power Required (sold separately)
SPECIFICATIONS
MODEL NUMBER: PRO-AFX-EQ2
AUDIO I/O: 1/4" TRS input and output (TRS enables Dual Path Functionality)
DSP: 32-bit processing
DIMENSIONS
1.9" W x 3.8" D x 1.92" H (49mm W x 97mm D x 49mm H)
MATERIAL: Durable aluminum enclosure
CURRENT DRAW: 53mA, typical
POWER: 910-R AC Adapter (sold separately) or suitable filtered and regulated 5.5mm OD, 2.1mm ID Barrel Connector, Center = negative
ANALOG SIGNAL PATH:
Input impedance: 10M Ohm | Output impedance: 1k Ohm | Signal-to-noise: -100dB | Dynamic range: 100dB
DIGITAL SIGNAL PATH:
A/D, D/A conversion: 24-bit | Signal processing: 32-bit
